The Charter+ 5 800 Wh low-step is a versatile city e-bike ready to adapt to how and where you ride. Its adjustable cockpit lets you customise feel from upright and comfortable to a more active position, while an air-sprung 80 mm fork keeps the ride smooth. It comes ready to roll with a 10-speed Shimano CUES drivetrain for smooth shifting performance and a Bosch Performance Line PX motor with a huge 800 Wh battery that lets you explore far out there – and still have plenty of power for the ride back.

Stay connected with Bosch

The Bosch eBike Flow app gives you more control with digital locking, theft alerts, customizable ride modes, and navigation — all from your phone.

CLICK HERE TO LEARN MORE

Find your perfect fit

A fully adjustable stem lets you fine-tune your position every ride, from a more relaxed fit to a more active riding position.

WATCH THE SETUP VIDEO TO LEARN MORE

Shifting made effortless

Bosch and Shimano Auto Shift technology automatically adjusts your gears based on terrain and speed — all you need to do is enjoy the ride.

A better battery experience

Charter+ comes with a high-capacity, top-eject Bosch battery for long rides and easy charging. The color-matched, lockable magnetic cover makes it secure, sleek, and simple to use.

MIK HD Rear Rack

This MIK HD rear rack supports weight up to 60lbs making it compatible for pretty much everything from child seats, side panniers, baskets and pet carriers.

Versatile visibility

Stay seen with daytime running lights powered by the main battery. The front light turns with your steering, and high beam brightens the road after dark.

What is the range?

To see how far you can ride your electric bike on a single charge, check out Bosch’s range calculator.

CLICK HERE TO CHECK YOUR RANGE

Rama:	Premium Alpha Platinum Aluminum frame, top-load PowerPack, integrated cockpit routing, 135x5mm QR
Prednja vilica:	SR Suntour Mobie 34, tapered steerer tube, air spring, adjustable rebound and compression, lockout, 100mm QR, 80mm travel
Prednja glavčina:	Shimano TC500, centerlock, 110x15 mm thru axle
Zadnja glavčina:	Shimano TC500-HM
Obruči:	Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve / Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve
Žbice:	14 g stainless steel, black
Gume:	Bontrager E6 Hard-Case Lite, reflective, wire bead, 60 tpi, 27.5x2.4'
Ručice mjenjača:	Shimano CUES U6000 w/optical gear display, 10-speed
Zadnji mjenjač:	Shimano CUES U6000 GS
Pogon:	ProWheel alloy, 170 mm length
Lančanik pogona:	Alloy, with 40T narrow-wide steel ring, alloy guard
Kazeta:	Shimano CUES LG400, LINKGLIDE, 11-48, 10-speed
Lanac:	Shimano LG500, 9/10/11-speed
Pedale:	Bontrager City pedals
Sjedalo:	Bontrager Commuter Comp
Cijev sjedala:	Aluminium with suspension, 300 mm long, with adjustable spring rate (Size: L, XL: 350 mm long)
Kormilo:	Alloy, 31.8 mm clamp, 25 mm rise, 630 mm width
Navlake kormila:	Trek ergonomic PRO, lock-on
Lula kormila:	Bontrager alloy, 31.8mm clamp, adjustable rise, Blendr compatible, 80mm length
Kočnice:	Shimano BR-MT420 hydraulic disc
Baterija:	Bosch PowerTube 800 Wh, smart system
Punjač:	Bosch standard 2A, 230V, smart system
Prikaz:	Bosch Kiox 500, smart system + Bosch LED remote, smart system
Motor:	Bosch Smart System PX, 90 Nm, 250 W, 25 km/h max assist
Prednje svjetlo:	Trek LED, 400 lumen low/800 lumen high, headlight
Zadnje svjetlo:	Trek LED, taillight
Nogar:	Pletscher Comp Flex 40
Težina:	M - 27.30 kg / 60.19 lb (excluding battery)
Godina modela:	2026
E-Bike Klasifikacija:	Class 1

BICIKL TREK e-Bike Charter+ 5 R10, Bosch Performance Line 800 Wh, LowStep L Lunar Silver / 2026

Boja:
Veličina:

• L

Materijal: ALLOY

Kategorija: E-BICIKLI
Proizvođač: TREK
